Technical Specification:

• Supports up to 4 HART channels. Each HART channel can be used as a primary or secondary master.
• Each HART interface supports point-to-point mode and multidrop mode.
  • Point-to-Point mode supports burst communication.
  • Multi-drop mode supports up to 15 HART instruments to be connected. Note: The actual number of connections depends on the field situation.
• Supports all commands of the HART protocol.
  • Each HART command can be configured to different output mode: change-of-state output, polling output, initialization output or disable output;
  • Supports up to 127 HART commands. Max output data: 1440 bytes; Max input data: 1440 bytes.
  • Supports HART 7 commands.
• Supports standard PROFINET RT and IRT protocols.
• Supports 4 Modbus TCP connections and up to 512 commands at the same time.
• Supports PROFINET MRP ring redundancy function.
• Power supply: 24VDC (9V-30V), 250mA (24VDC). Power interface isolation: 1.5KV.
• Operating Temp: -40°F to 158°F (-40°C to 70°C); Rel. Humidity: 5% to 95% (non-condensing).
• Dimension (W* H* D): 1.33 in*4.56 in*4.1 in (34mm*116mm*105mm).
• Installation: 35mm DIN RAIL.
• Protection Level: IP20.
