Technical Specification:

• EtherCAT MainDevice interface supports CoE and complies with CiA 402 standard.
• EtherCAT MainDevice interface supports a maximum of 32 devices connections, supports device types including Single/Multi-Axis Servo, IO Coupler, Frequency Converter, etc.
• EtherCAT MainDevice interface supports SM and DC synchronization modes, with a configurable distributed clock (DC) cycle ranging from 2ms to 20ms.
• Supports hot swapping of EtherCAT devices (online replacement), allowing the replacement of a slave without affecting the normal communication of already connected slaves.
• Supports endian conversion. (Supports one-click switching between big-endian and little-endian display of process data based on the configured object.)
• Supports a minimum protocol conversion interval time of 4ms.
• Ethernet auto-negotiation with built-in Ethernet switching capabilities, supports cascading.
• Supports the ODVA standard EtherNet/IP communication protocol as an EtherNet/IP Adapter (Slave).
• Maximum EtherNet/IP connection size:
  • Maximum number of input bytes: 492 Bytes.
  • Maximum number of output bytes: 492 Bytes.
• Power supply: 24VDC (9V - 30V), 80mA (24VDC).
• Working temperature:-40°F to 158°F (-40°C to 70°C), relative humidity: 5% - 95% (non-condensing).
• External dimensions (W x H x D): 1.3in x 4.6in x 4.1in ( 34mm*116mm*105mm).
• Mounting:DIN Rail Mounting (35mm).
